Mekitec MidMEKI™ X-Ray Inspection System

MIDMEKI™ X-Ray Inspection System: Intelligent Inspection for Medium to Large Packaged Foods

The MIDMEKI™ X-Ray Inspection System from Mekitec is an advanced automated quality control solution developed specifically for medium-sized and larger primary packaged food products. Combining the compact efficiency of the MEKI™ platform with a wider conveyor and expanded detection area, MIDMEKI™ enables producers to inspect bigger items and multi-product trays with exceptional precision whilst maintaining an efficient production footprint.

AI-Driven Software Architecture Reduces Cost

Powered by intelligent AI-driven X-ray image processing, MIDMEKI™ delivers high detection performance through advanced software algorithms rather than costly hardware expansion. This software-first architecture enhances contaminant detection accuracy whilst reducing the need for expensive mechanical components and complex system designs. The result is a highly capable inspection solution that provides premium performance with a significantly lower total cost of ownership compared to many competing X-ray systems.

Reliable Detection Across Diverse Products

MIDMEKI™ effectively detects foreign objects such as metal fragments, stones, glass, calcified bones, and dense plastics whilst simultaneously verifying product integrity and supporting full production traceability. Its inspection reliability remains consistent even when scanning products with high moisture or salt content. Packaging materials such as metallised films and aluminium containers do not interfere with imaging accuracy, ensuring dependable inspection across diverse food categories and packaging formats.

Focused on Essential Value

Designed with food producers in mind, MIDMEKI™ focuses on essential inspection capabilities that deliver maximum value. By concentrating on primary packaging inspection, the system avoids unnecessary complexity whilst providing the performance levels manufacturers truly require for food safety compliance and brand protection.

Hygienic Construction and Regulatory Compliance

The system is constructed from durable brushed stainless steel and features an EU and FDA-approved food-grade conveyor belt that supports hygienic operation and long-term reliability. MIDMEKI™ is compliant with the UK X-ray Supermarket Code of Practice, meeting the stringent requirements for food safety inspection systems supplying the UK retail sector. Automatic rejection is supported through optional air blast or pusher systems with collection bins, allowing contaminated products to be removed without disrupting production flow.

Powerful X-Ray Technology for Larger Products

MIDMEKI™ operates with a powerful and efficient X-ray generator rated between 40 and 80 kV with output up to 200 W, enabling strong penetration for larger and denser products whilst maintaining energy efficiency. Radiation leakage remains below strict international safety limits to ensure operator safety. A high-resolution linear scanner detector with 0.4 mm resolution produces detailed X-ray images for precise software analysis.

User-Friendly Interface and Connectivity

The system runs the Mekitec X-Ray Inspection Software on a Windows 10 platform, delivering a stable and intuitive operator experience via a bright 12-inch colour TFT LCD touchscreen interface. Operators can easily manage inspection parameters, monitor performance, and maintain traceability records. USB and Ethernet connectivity enable seamless integration with factory management and reporting systems.

Flexible Configurations for Varied Production Needs

Multiple conveyor configurations allow MIDMEKI™ to adapt to different production needs. Conveyor speeds range from slow precision handling to high-throughput processing depending on the selected gearbox configuration. Load capacity supports lighter products up to 5 kg and heavier product batches up to 20 kg, making the system versatile for varied manufacturing requirements.

Robust Performance in Industrial Environments

MIDMEKI™ performs reliably in demanding industrial environments with operating temperatures from 0 to 35 degrees Celsius and optional cooling available for higher-stress conditions. The system features an IP65 protection rating, offering strong resistance against dust and water exposure. It operates effectively in non-condensing humidity levels between 30 and 85 per cent.

Safety and Standards Compliance

Safety and compliance are central to the design. MIDMEKI™ meets EN and FDA radiation protection standards and incorporates a certified safety circuit compliant with Category 3 and Performance Level PL d machinery safety requirements.

Expanded Detection Area

The enlarged detection area accommodates taller and wider products whilst maintaining precise contaminant identification. Products must fit fully within the inspection zone, and maximum product length depends on the reject configuration selected. Standard configurations support products up to 300 mm in length, whilst extended versions allow products up to 500 mm.

Cost-Effective Innovation for Larger Products

With its AI-enhanced inspection intelligence, expanded inspection capacity, durable hygienic construction, and reduced dependence on costly hardware upgrades, MIDMEKI™ represents a cost-effective innovation-led solution for food manufacturers needing to inspect larger packaged products. It delivers exceptional value, operational efficiency, and reliable food safety performance that rivals more expensive traditional X-ray inspection systems.
